Pipeline Workflows

Snow-White integrates into your CI/CD pipeline to enforce API coverage automatically. Two primary workflow patterns are supported depending on how your repositories are organized.

Specification-First Workflow

The recommended workflow for teams practicing specification-first API design. The OpenAPI specification is the source of truth and is published to the spec repository before implementation begins.

How it works:

1. A developer writes or updates the OpenAPI spec and opens a PR.
2. On merge, the spec is published to the central spec repository (e.g. JFrog Artifactory).
3. Snow-White’s sync job picks up the new spec and indexes it.
4. The service implementation PR runs integration tests with the OTEL agent attached.
5. The CI pipeline triggers snow-white calculate — the CLI evaluates the quality gate and fails the build if coverage is insufficient.

Mono-Repository Workflow

For teams using a mono-repository, the spec and implementation live side-by-side and are always in sync.

How it works:

1. The spec and implementation are committed together.
2. The CI pipeline builds the service, runs integration tests with OTEL instrumentation, and publishes the spec.
3. Snow-White indexes the spec and correlates it with the traces produced during the test run.
4. snow-white calculate evaluates the quality gate inline in the same pipeline.

CLI Quick Reference

The Snow-White CLI is the integration point for both workflows.

Minimal config file (snow-white.json):

{
  "url": "http://<snow-white-host>",
  "qualityGate": "basic-coverage",
  "apiInformation": [
    {
      "serviceName": "my-service",
      "apiName": "my-api",
      "apiVersion": "1.0.0"
    }
  ]
}

Trigger a coverage calculation:

node toolkit/cli/target/cli/index.js calculate --configFile snow-white.json

Exit Code	Meaning
0	Quality gate passed
non-zero	Quality gate failed or error occurred

See toolkit/cli/README.md for all exit codes and options.

Setting Up the Quality Gate Step

Add the coverage check as a CI step after your integration tests.

GitHub Actions example:

- name: Calculate API Coverage
  run: |
    node toolkit/cli/target/cli/index.js calculate \
      --configFile snow-white.json
  env:
    SNOW_WHITE_URL: $

The step will fail the workflow if the quality gate is not met, preventing the PR from merging.

See Quality Gate Criteria for the full list of checks available to include in a gate.
